difuzor Beyma 12Lex1000Fe

Acasa/Difuzoare/12 inch/difuzor Beyma 12Lex1000Fe
Nou

difuzor Beyma 12Lex1000Fe

In Stock

175,95  + TVA



putere:
1000W AES,
sensibilitate:
95 dB/1W/1M,
domeniu de frecvenţă:
45-1500Hz,
impedanţă:
8 ohm,
frecvenţă rezonanţă:
49Hz,
preţ kit reparaţii:
—————–

12Lex1000Fe

TECHNICAL SPECIFICATIONS



Nominal diameter

300 mm 12 in

Nominal impedance

8 Ohm

Minimum impedance

7.6 ohm

Power capacity

1000 W AES

Program power

2000 W

Sensitivity

95 dB 1 W/1 m @ ZN

Frequency range

50-1500 Hz

Recommended enclosure volume

50 l

Voice coil diameter

88.9 mm 3.5 in

BL factor

24.6 N/A

Moving mass

0.118 kg

Winding length

27 mm

Air gap height

12 mm

Xdamage pp

51 mm

THIELE SMALL PARAMETERS



Fs

49 Hz

Re

5.4 ohm

Qms

3.6

Qes

0.32

Qts

0.3

Vas

38.4 l

Cms

89 µm / N

Rms

10.1 kg/s

Efficiency %

1.3

Sd

0.055 m²

Xmax

11 mm

Vd

605 cm³

Le @1 kHz

1.7 mH

CONSTRUCTIVE DETAILS



Depth

166 mm 6.5 in

Net weight

10.4 kg 22.9 lb

Total weight

11.1 kg 24.4 lb

Magnet

Ferrite
