difuzor Beyma 12SW1300Nd

Acasa/Difuzoare/12 inch/difuzor Beyma 12SW1300Nd

difuzor Beyma 12SW1300Nd

In Stock

284,90  + TVA

putere : 1300 @ 2600 W
sensibilitate : 97 dB @ 1w @ 1m
domeniu de frecvenţă : 25 – 1800 Hz
impedanţă : 8 ohm
frecvenţă rezonanţă : 44 Hz
preţ kit reparaţii : 81,90 euro+tva



TECHNICAL SPECIFICATIONS



Nominal diameter 300 mm 12 in
Nominal impedance 8 Ohm
Minimum impedance 6.2 ohm
Power capacity 1200 W AES
Program power 2400 W
Sensitivity 96 dB 1 W @ 1 m @ 2Π
Frequency range 25-1800 Hz
Maximum recom. frequency 200 Hz
Recommended enclosure volume 12 / 60 l 0.7 / 2.24 ft³
Voice coil diameter 100 mm 4 in
BL factor 25.3 N / A
Moving mass 0.118 kg
Winding length 25 mm
Air gap height 14 mm
Xdamage pp 60 mm

THIELE SMALL PARAMETERS



Fs 45 Hz
Re 4.9 ohm
Qms 12.07
Qes 0.27
Qts 0.26
Vas 45 l
Cms 105.5 µm / N
Rms 2.77 kg / s
Efficiency % 1.47
Sd 0.055 m²
Xmax 10 mm
Vd 550 cm³
Le @1 kHz 3.25 mH

CONSTRUCTIVE DETAILS



Net weight 7.2 kg 15.84 lb
Total weight 8 kg 17.6 lb
Magnet Neodymium
