difuzor Beyma 15CMV2

Acasa/Difuzoare/15 inch/difuzor Beyma 15CMV2
Nou

difuzor Beyma 15CMV2

In Stock

75,00  + TVA

putere  350 W AES
sensibilitate  97 dB @ 2.83V @ 1m
domeniu de frecvenţă  50 – 4000 HZ
impedanţă  8 ohm
frecvenţă rezonanţă  49 Hz

15CMV2

TECHNICAL SPECIFICATIONS



Nominal diameter

380 mm 15 in

Nominal impedance

8 Ohm

Minimum impedance

7.5 ohm

Power capacity

350 W AES

Program power

700 W

Sensitivity

97 dB 1 W @ 1 m @ ZN

Frequency range

50-4000 Hz

Recommended enclosure volume

75 l

Voice coil diameter

76.2 mm 3 in

BL factor

18.8 N/A

Moving mass

0.106 kg

Winding length

17.5 mm

Air gap height

7 mm

Xdamage pp

35 mm

THIELE SMALL PARAMETERS

Fs

49 Hz

Re

6 ohm

Qms

4.1

Qes

0.55

Qts

0.49

Vas

104 l

Cms

95 µm / N

Rms

8.1 kg/s

Efficiency %

2.3

Sd

0.088 m²

Xmax

7 mm

Vd

616 cm³

Le @1 kHz

1.2 mH

CONSTRUCTIVE DETAILS

Depth

165 mm 6.5 in

Net weight

6 kg 13.3 lb

Total weight

7 kg 15.4 lb

Magnet

Ferrite
