difuzor Beyma 15SW1300Nd

Acasa/Difuzoare/15 inch/difuzor Beyma 15SW1300Nd

difuzor Beyma 15SW1300Nd

In Stock

317,90  + TVA

putere : 1300 @ 2600 W
sensibilitate : 97 dB @ 1w @ 1m
domeniu de frecvenţă : 25 – 1800 Hz
impedanţă : 8 ohm
frecvenţă rezonanţă : 44 Hz
preţ kit reparaţii : 88,90 Euro + TVA



TECHNICAL SPECIFICATIONS



Nominal diameter 380 mm 15 in
Nominal impedance 8 Ohm
Minimum impedance 5.8 ohm
Power capacity 1300 W AES
Program power 2600 W
Sensitivity 97 dB 1 W @ 1 m @ 2Π
Frequency range 25-1800 Hz
Maximum recom. frequency 200 Hz
Recommended enclosure volume 40 / 150 l / 1.4 / 5.3 ft³
Voice coil diameter 100 mm 4 in
BL factor 25.1 N / A
Moving mass 0.160 kg
Winding length 25 mm
Air gap height 14 mm
Xdamage pp 60 mm

THIELE SMALL PARAMETERS



Fs 44 Hz
Re 5.2 ohm
Qms 14.7
Qes 0.37
Qts 0.36
Vas 89.6 l
Cms 81.5 µm/ N
Rms 3.02 kg / s
Efficiency % 1.99
Sd 0.088 m²
Xmax 10 mm
Vd 836 cm³
Le @1 kHz 3.45 mH

CONSTRUCTIVE DETAILS



Net weight 7.7 kg 16.94 lb
Total weight 8.7 kg 19.14 lb
Magnet Neodymium
