difuzor Beyma 6CMV2

Acasa/Difuzoare/6 inch/difuzor Beyma 6CMV2

difuzor Beyma 6CMV2

In Stock

31,95  + TVA



putere: 220W AES,
sensibilitate: 94dB/1W/1M,
domeniu de frecvenţă: 95-8000Hz,
impedanţă: 8 ohm,
frecvenţă rezonanţă: 90Hz,
preţ kit reparaţii: ———–





TECHNICAL SPECIFICATIONS



Nominal diameter 165 mm 6.5 in
Nominal impedance 8 Ohm
Minimum impedance 6.7 ohm
Power capacity 220 W AES
Program power 440 W
Sensitivity 94 dB 1 W @ 1m @ 2Π
Frequency range 95-8000 Hz
Recommended enclosure volume 9 I
Voice coil diameter 38.1 mm 1.5 in
BL factor 9.4 N /A
Moving mass 0.013 kg
Winding length 14 mm
Air gap height 6 mm
Xdamage pp 30 mm

THIELE SMALL PARAMETERS



Fs 90 Hz
Re 5.3 ohm
Qms 1.4
Qes 0.45
Qts 0.34
Vas 6.5 l
Cms 235 µm / N
Rms 5.5 kg / s
Efficiency % 1
Sd 0.014 m²
Xmax 5.7 mm
Vd 80 cm³
Le @1 kHz 0.5 mH

CONSTRUCTIVE DETAILS

Depth 80 mm 3.1 in

Net weight 2.2 kg 4.84 lb
Total weight 2.3 kg 5.06 lb
Magnet Ferrite
