difuzor Beyma SM110 N

Acasa/Difuzoare/10 inch/difuzor Beyma SM110 N

difuzor Beyma SM110 N

In Stock

54,90  + TVA

putere : 200W AES
sensibilitate : 95dB @ 2.83V @ 1m
domeniu de frecvenţă : 45 – 6500Hz
impedanţă : 8 ohm
frecvenţă rezonanţă : 43Hz
preţ kit reparaţii : 36,90 Euro + TVA



TECHNICAL SPECIFICATIONS



Nominal diameter 250 mm 10 in
Nominal impedance 8 Ohm
Minimum impedance 7.2 ohm
Power capacity 200 W AES
Program power 400 W
Sensitivity 95 dB 1 W @ 1m @ 2Π
Frequency range 45-6500 Hz
Recommended enclosure volume 20 / 50 l 0.71 / 1.77 ft.³
Voice coil diameter 51.7 mm 2 in
BL factor 13.2 N /A
Moving mass 0.038 kg
Winding length 15 mm
Air gap height 7 mm
Xdamage pp 28 mm

THIELE SMALL PARAMETERS



Fs 43 Hz
Re 6.2 ohm
Qms 7.88
Qes 0.37
Qts 0.35
Vas 65 l
Cms 368 µm / N
Rms 1.3 kg / s
Efficiency % 1.4
Sd 0.0355 m²
Xmax 4 mm
Vd 141 cm³
Le @1 kHz 1.7 mH

CONSTRUCTIVE DETAILS



Net weight 3.5 kg 7.72 lb
Total weight 3.9 kg 8.6 lb
Magnet Ferrite
