difuzor coaxial Beyma 8CFX260Nd
In Stock
380,95 € + TVA
| putere (LF/HF): | 250/60W RMS |
| sensibilitate(LF/HF): | 97/103 dB/1W/1M |
| domeniu de frecvenţă: | 100-20000 Hz |
| impedanţă(LF/HF): | 8/8 ohm |
| frecvenţă rezonanţă: | 100 Hz |
| preţ kit reparaţii: | 60,95(HF)/81,95(LF) Euro+TVA |
Descărcări: beyma-speakers-data-sheet-coaxial-8CFX260Nd
Technical specifications
LF Recone kit ref.
5M8CFX26ND8
HF diaphragm ref.
5MCP758
Nominal diameter
200 mm 8 in
Nominal impedance LF/HF
8/8 ohm
Minimum impedance LF/HF
6.8/6.9 ohm
Power capacity LF/HF
250/60 W AES
Program power LF/HF
500/120 W
Sensitivity LF/HF
97/103 dB 1W/1m @ ZN
Frequency range
100-20000 Hz
Recom. crossover frequency
1.5 kHz or higher (12dB/oct min slope)
Voice coil diameter LF/HF
63.5/72.4 mm – 2.5/2.85 in
Dispersion (conical)
70º
BL factor
13.5 N/A
Moving mass
0.021 kg
Winding length
15 mm
Xdamage pp
20 mm
Parameters Thiele & Small
Fs
100 Hz
Re
5.2 ohm
Qms
4.8
Qes
0.37
Qts
0.35
Vas
8 l
Cms
119 µm / N
Rms
2.7 kg/s
Efficiency %
2.2
Sd
0.022 m²
Xmax
6 mm
Vd
132 cm³
Le @1 kHz
0.23 mH
Construction details
Net weight
4.9 kg 10.8 lb
Total weight
5.2 kg 11.5 lb
Magnet
Neodymium
