difuzor de banda larga Beyma 12GA50

Acasa/Difuzoare/bandă largă/difuzor de banda larga Beyma 12GA50
beyma-speakers-product-picture-full-range-12GA50

difuzor de banda larga Beyma 12GA50

In Stock

86,95  + TVA



putere: 250W AES,
sensibilitate: 102dB/1W/1M,
domeniu de frecvenţă: 70-18000Hz,
impedanţă: 8 ohm,
frecvenţă rezonanţă: 90Hz,
preţ kit reparaţii: 37,95 Euro + TVA



TECHNICAL SPECIFICATIONS



Nominal diameter 300 mm 12 in
Nominal impedance 8 Ohm
Minimum impedance 6.8 ohm
Power capacity 250 W AES
Program power 500 W
Sensitivity 102 dB 1 W @ 1m @ 2Π
Frequency range 70-18000 Hz
Recommended enclosure volume 20 / 70 l 0.7 / 2.45 ft.³
Voice coil diameter 52 mm 2 in
BL factor 10 N / A
Moving mass 0.034 kg
Winding length 9 mm
Air gap height 7 mm
Xdamage pp 24 mm

THIELE SMALL PARAMETERS



Fs 90 Hz
Re 6.2 ohm
Qms 14.8
Qes 1.26
Qts 1.16
Vas 34 l
Cms 87 µm / N
Rms 1.34 Kg / S
Efficiency % 2.1
Sd 0.053 m²
Xmax 2 mm
Vd 105 cm³
Le @1 kHz 0.6 mH

CONSTRUCTIVE DETAILS



Net weight 3.55 kg / 7.81 lb
Total weight 4 kg 8.81 lb
Magnet Ferrite
