tweeter Beyma CP/12/N

beyma-speakers-product-picture-compression-tweeter-CP12N

tweeter Beyma CP/12/N

In Stock

35,95  + TVA

Putere: 15 W AES , program 30 W
Sensibilitate: 107 dB /1W /1M
Domeniu de frecvență: 3000-20000 Hz
Impedanță: 8 Ohm
Frecvență crossover recomandată: 6 kHz or higher (12 dB/oct. min slope)
Dispersie: 40° conical
Preț kit reparații: 19,95 EURO+TVA

Descărcări: beyma-speakers-data-sheet-compression-tweeter-CP12N

TECHNICAL SPECIFICATIONS



Nominal impedance
8 Ohm
Minimum impedance
8 ohm @ 8 kHz
Sensitivity
107 dB 1 W @ 1 m
Re
5 ohm
Frequency range
3000-20000 Hz
Power capacity
15 W AES
Program power
30 W
Recom. crossover frequency
6 kHz or higher (12 dB/oct. min slope)
Dispersion HxV
40º conical
Voice coil diameter
25.8 mm 1 in
Flux density
1.4 T
BL factor
4 N/A
Diaphragm material
Aluminium

CONSTRUCTION DETAILS



External diameter
87×87 mm 3.4×3.4 in
Depth
72 mm 2.83 in
Cutout diameter
ø 74 mm 2.9 in
Bolt circle diameter
91 mm 3.58 in
Net weight
0.75 kg 1.65 lb
Total weight
0.85 kg 1.87 lb
Magnet
Ferrite
