difuzor Beyma 10G40

Acasa/Difuzoare/10 inch/difuzor Beyma 10G40

difuzor Beyma 10G40

In Stock

96,90  + TVA

putere : 300W AES
sensibilitate : 95dB @ 2.83V @ 1m
domeniu de frecvenţă : 45 – 4000Hz
impedanţă : 8 ohm
frecvenţă rezonanţă : 55Hz
preţ kit reparaţii : 53,90 Euro + TVA



TECHNICAL SPECIFICATIONS



Nominal diameter 250 mm 10 in
Nominal impedance 8 Ohm
Minimum impedance 6.6 ohm @ 5.3 kHz
Power capacity 400 W AES
Program power 800 W
Sensitivity 95 dB 1 W @ 1m @ 2Π
Frequency range 45-4000 Hz
Recommended enclosure volume 20 / 70 l 0.7 / 2.6 ft.³
Voice coil diameter 77 mm 3 in
BL factor 17 N / A
Moving mass 0.052 kg
Winding length 17.5 mm
Air gap height 7 mm
Xdamage pp 28 mm

THIELE SMALL PARAMETERS



Fs 45 Hz
Re 6.2 ohm
Qms 7.1
Qes 0.32
Qts 0.3
Vas 49 l
Cms 241 µm / N
Rms 2.1 kg / s
Efficiency % 1.4
Sd 0.038 m²
Xmax 7 mm
Vd 266 cm³
Le @1 kHz 0.6 mH

CONSTRUCTIVE DETAILS



Net weight 5.7 kg 12.5 lb
Total weight 6 kg 13.2 lb
Magnet Ferrite
