12Lex1300Nd
TECHNICAL SPECIFICATIONS
Nominal diameter |
300 mm 12 in |
Nominal impedance |
8 Ohm |
Minimum impedance |
6.8 ohm |
Power capacity |
1300 W AES |
Program power |
2600 W |
Sensitivity |
96 dB 1 W/1 m @ ZN |
Frequency range |
45-1500 Hz |
Recommended enclosure volume |
45 l |
Voice coil diameter |
101.6 mm 4 in |
BL factor |
26.4 N/A |
Moving mass |
0.125 kg |
Winding length |
28 mm |
Air gap height |
14 mm |
Xdamage pp |
65 mm |
THIELE SMALL PARAMETERS
Fs |
45 Hz |
Re |
5 ohm |
Qms |
4.2 |
Qes |
0.25 |
Qts |
0.24 |
Vas |
43 l |
Cms |
100 µm / N |
Rms |
8.4 kg/s |
Efficiency % |
1.5 |
Sd |
0.055 m² |
Xmax |
11 mm |
Vd |
605 cm³ |
Le @1 kHz |
1.3 mH |
CONSTRUCTIVE DETAILS
Depth |
176 mm 6.9 in |
Net weight |
8.3 kg 18.3 lb |
Total weight |
9 kg 19.8 lb |
Magnet |
Neodymium |
