difuzor Beyma 15MCB700

Acasa/Difuzoare/15 inch/difuzor Beyma 15MCB700
Nou

difuzor Beyma 15MCB700

In Stock

149,95  + TVA

putere:
700W AES,
sensibilitate:
99 dB/1W/1M,
domeniu de frecvenţă:
45-4000Hz,
impedanţă:
8 ohm,
frecvenţă rezonanţă:
44Hz,
preţ kit reparaţii:
—————–

15MCB700

TECHNICAL SPECIFICATIONS



Nominal diameter

380 mm 15 in

Nominal impedance

8 Ohm

Minimum impedance

7 ohm

Power capacity

700 W AES

Program power

1400 W

Sensitivity

99 dB 1 W/1 m @ ZN

Frequency range

45-4000 Hz

Recommended enclosure volume

60 l

Voice coil diameter

76.2 mm 3 in

BL factor

20 N/A

Moving mass

0.096 kg

Winding length

18 mm

Air gap height

9.5 mm

Xdamage pp

45 mm

THIELE SMALL PARAMETERS



Fs

44 Hz

Re

5.3 ohm

Qms

5.4

Qes

0.36

Qts

0.34

Vas

148 l

Cms

135 µm / N

Rms

4.9 kg/s

Efficiency %

3.4

Sd

0.088 m²

Xmax

7 mm

Vd

385 cm³

Le @1 kHz

0.9 mH

CONSTRUCTIVE DETAILS



Depth

177 mm 7 in

Net weight

8 kg 17.6 lb

Total weight

9 kg 19.8 lb

Magnet

Ferrite
