difuzor Beyma 12MC500

Acasa/Difuzoare/12 inch/difuzor Beyma 12MC500

difuzor Beyma 12MC500

In Stock

108,90  + TVA

putere : 500 / 1000W AES
sensibilitate : 98db / 1w /1m
domeniu de frecvenţă : 50 – 5500 hz
impedanţă : 8 ohmi
frecvenţă rezonanţă : 57 hz



TECHNICAL SPECIFICATIONS



Nominal diameter 300 mm 12 in
Nominal impedance 8 Ohm
Minimum impedance 5.8 ohm
Power capacity 500 W AES
Program power 1000 W
Sensitivity 98 dB 1 W @ 1 m @ ZN
Frequency range 60-5000 Hz
Recommended enclosure volume 30 / 100 l 1.06 / 3.53 ft.³
Voice coil diameter 63.5 mm 2.5 in
BL factor 17.2 N / A
Moving mass 0.059 kg
Winding length 19.5 mm
Air gap height 10 mm
Xdamage pp 40 mm

THIELE SMALL PARAMETERS



Fs 57 Hz
Re 5.5 ohm
Qms 8.58
Qes 0.39
Qts 0.38
Vas 54.9 l
Cms 128 µm / N
Rms 2.58 kg / s
Efficiency % 2.53
Sd 0.055 m²
Xmax 8 mm
Le @1 kHz 0.7 mH

CONSTRUCTIVE DETAILS



Net weight 5.86 kg 12.92 lb
Magnet Ferrite
