difuzor Beyma 15LEX1600Fe

Acasa/Difuzoare/15 inch/difuzor Beyma 15LEX1600Fe
Nou

difuzor Beyma 15LEX1600Fe

In Stock

244,95  + TVA

putere:
1600W AES,
sensibilitate:
96 dB/1W/1M,
domeniu de frecvenţă:
40-1500Hz,
impedanţă:
8 ohm,
frecvenţă rezonanţă:
38 Hz,
preţ kit reparaţii:
——- Euro+TVA

15LEX1600Fe

TECHNICAL SPECIFICATIONS



Nominal diameter

380 mm 15 in

Nominal impedance

8 Ohm

Minimum impedance

6.1 ohm

Power capacity

1600 W AES

Program power

3200 W

Sensitivity

96 dB 1 W/1 m @ ZN

Frequency range

40-1500 Hz

Recommended enclosure volume

94 l

Voice coil diameter

101.6 mm 4 in

BL factor

25.8 N/A

Moving mass

0.179 kg

Winding length

32 mm

Air gap height

15 mm

Xdamage pp

60 mm

THIELE SMALL PARAMETERS



Fs

38 Hz

Re

5.3 ohm

Qms

6.9

Qes

0.34

Qts

0.33

Vas

106 l

Cms

97 µm / N

Rms

6.2 kg/s

Efficiency %

1.7

Sd

0.088 m²

Xmax

13 mm

Vd

1144 cm³

Le @1 kHz

1.7 mH

CONSTRUCTIVE DETAILS



Depth

191 mm 7.5 in

Net weight

13.9 kg 30.6 lb

Total weight

14.9 kg 32.8 lb

Magnet

Ferrite
