difuzor Beyma 15MC500

Acasa/Difuzoare/15 inch/difuzor Beyma 15MC500

difuzor Beyma 15MC500

In Stock

120,90  + TVA

putere :
500 / 1000W AES
sensibilitate :
98dB / 1W / 1m
domeniu de frecvenţă :
40 – 4000 Hz
impedanţă :
8 ohm
frecvenţă rezonanţă :
46 hz
preţ kit reparaţii :
65,90 Euro + TVA

TECHNICAL SPECIFICATIONS



Nominal diameter

380 mm 15 in

Nominal impedance

8 Ohm

Minimum impedance

6.6 ohm

Power capacity

500 W AES

Program power

1000 W

Sensitivity

98 dB 1 W @ 1 m @ ZN

Frequency range

50-4000 Hz

Recommended enclosure volume

60 / 150 l 2.1 / 5.25 ft³

Voice coil diameter

63.5 mm 2.5 in

BL factor

18.2 N/A

Moving mass

0.098 kg

Winding length

19.5 mm

Air gap height

10 mm

Xdamage pp

40 mm

THIELE SMALL PARAMETERS



Fs

46 Hz

Re

5.7 ohm

Qms

8

Qes

0.49

Qts

0.46

Vas

131.5 l

Cms

120 µm / N

Rms

3.5 kg / s

Efficiency %

2.55

Sd

0.088 m²

Xmax

8 mm

Vd

704 cm³

Le @1 kHz

1.1 mH

CONSTRUCTIVE DETAILS



Net weight

6.2 kg 13.67 lb

Total weight

7.2 kg 15.87 lb

Magnet

Ferrite
