difuzor Beyma 15MC700

Acasa/Difuzoare/15 inch/difuzor Beyma 15MC700

difuzor Beyma 15MC700

In Stock

158,95  + TVA

putere:
700W AES,
sensibilitate:
98 dB/1W/1M,
domeniu de frecvenţă:
45-4000Hz,
impedanţă:
8 ohm,
frecvenţă rezonanţă:
41Hz,
preţ kit reparaţii:
82,95 euro+TVA

TECHNICAL SPECIFICATIONS



Nominal diameter

380 mm 15 in

Nominal impedance

8 Ohm

Minimum impedance

7.6 ohm

Power capacity

700 W AES

Program power

1400 W

Sensitivity

98 dB 1 W @ 1 m @ ZN

Frequency range

45-4000 Hz

Voice coil diameter

76.2 mm 3 in

BL factor

20.6 N/A

Moving mass

0.106 kg

Winding length

23 mm

Air gap height

8 mm

Xdamage pp

40 mm

THIELE SMALL PARAMETERS



Fs

41 Hz

Re

5.9 ohm

Qms

4.8

Qes

0.38

Qts

0.35

Vas

153 l

Cms

140 µm / N

Rms

5.7 kg/s

Efficiency %

2.7

Sd

0.088 m²

Xmax

9.8 mm

Vd

880 cm³

Le @1 kHz

1mH

CONSTRUCTIVE DETAILS



Depth

175 mm 6.89 in

Net weight

7.5 kg 16.5 lb

Total weight

8.5 kg 18.7 lb

Magnet

Ferrite
