difuzor Beyma 18PW1400Fe

Acasa/Difuzoare/18 inch/difuzor Beyma 18PW1400Fe

difuzor Beyma 18PW1400Fe

In Stock

257,90  + TVA

putere :
1400W AES
sensibilitate :
98dB @ 2.83V @ 1m
domeniu de frecvenţă :
25 – 1800 Hz
impedanţă :
4 / 8 ohm
frecvenţă rezonanţă :
32 Hz
preţ kit reparaţii :
80,90 euro+tva

TECHNICAL SPECIFICATIONS



Nominal diameter

460 mm 18 in

Nominal impedance

8 Ohm

Minimum impedance

5.3 ohm

Power capacity

1400 W AES

Program power

2800 W

Sensitivity

98 dB 1 W @ 1 m

Frequency range

25-1800 Hz

Maximum recom. frequency

200 Hz

Recommended enclosure volume

80 / 200 l 2.8 / 7 ft³

Voice coil diameter

100 mm 4 in

BL factor

29 N/A

Moving mass

0.230 kg

Winding length

25 mm

Air gap height

12 mm

Xdamage pp

55 mm

THIELE SMALL PARAMETERS



Fs

32 Hz

Re

5.05 ohm

Qms

10.23

Qes

0.28

Qts

0.27

Vas

228.9 l

Cms

103 µm / N

Rms

4.62 kg/s

Efficiency %

2.4

Sd

0.1255 m²

Xmax

10 mm

Vd

1251 cm³

Le @1 kHz

1.2 mH

CONSTRUCTIVE DETAILS



Net weight

16.9 kg 37.26 lb

Total weight

18.1 kg 39.98 lb

Magnet

Ferrite
