difuzor Beyma 21LEX1600Nd

Acasa/Difuzoare/21 inch/difuzor Beyma 21LEX1600Nd
Nou

difuzor Beyma 21LEX1600Nd

In Stock

399,00  + TVA

putere : 1600 /3200 W
sensibilitate : 99.5 dB / 1W /1m
domeniu de frecvenţă : 30-1000Hz
impedanţă : 8 ohmi
frecvenţă rezonanţă: 30 hz

21LEX1600Nd

TECHNICAL SPECIFICATIONS



Nominal diameter

540 mm 21 in

Nominal impedance

8 Ohm

Minimum impedance

7.2 ohm

Power capacity

1600 W AES

Program power

3200 W

Sensitivity

99.5 dB 1 W/1 m @ ZN

Frequency range

30-1000 Hz

Recommended enclosure volume

150 l

Voice coil diameter

101.6 mm 4 in

BL factor

33 N/A

Moving mass

0.305 kg

Winding length

32 mm

Air gap height

14 mm

Xdamage pp

65 mm

THIELE SMALL PARAMETERS



Fs

30 Hz

Re

5.4 ohm

Qms

4.4

Qes

0.29

Qts

0.27

Vas

394 l

Cms

92 µm / N

Rms

13 kg/s

Efficiency %

3.6

Sd

0.1734 m²

Xmax

13 mm

Vd

2254 cm³

Le @1 kHz

1.9 mH

CONSTRUCTIVE DETAILS



Depth

268 mm 10.6 in

Net weight

11.8 kg 26.01 lb

Total weight

14.3 kg 31.5 lb

Magnet

Neodymium
