difuzor coaxial Beyma, 15CXA400Nd
difuzor coaxial Beyma, 15CXA400Fe
<span class="woocommerce-Price-amount amount"><bdi>324,95 <span class="woocommerce-Price-currencySymbol">€</span></bdi></span> + TVA
difuzor coaxial Beyma, 15XA38Nd
<span class="woocommerce-Price-amount amount"><bdi>420,95 <span class="woocommerce-Price-currencySymbol">€</span></bdi></span> + TVA
In Stock
467,95 € + TVA
| putere (LF/HF): | 400/90W RMS, |
| sensibilitate(LF/HF): | 98/105 dB/1W/1M, |
| domeniu de frecvenţă: | 40-20000 Hz, |
| impedanţă(LF/HF): | 8/16 ohm, |
| frecvenţă rezonanţă: | 40 Hz, |
| preţ kit reparaţii: | 91,95 Euro+TVA |
TECHNICAL SPECIFICATIONS
Nominal impedance LF/HF
8/16 ohm
HF diaphragm ref.
5MCP756
LF Recone kit ref.
5M15CXA4ND8
Nominal diameter
380 mm 15 in
Minimum impedance LF/HF
6.6 / 10.9 ohm
Frequency range
40-20000 Hz
Power capacity LF/HF
400/90 W AES
Program power LF/HF
800/180 w
Sensitivity LF/HF
98/105 2.83 @ 1 m @ 2π
Recom. crossover frequency
1.5 kHz or higher (12dB/oct min slope)
Voice coil diameter LF/HF
101.6/72.4 mm – 4/2.85 in
Dispersion (conical)
60º
BL factor
19 N/A
Moving mass
0.084 kg
Winding length
16 mm
Xdamage pp
28 mm
PARAMETERS THIELE & SMALL
Fs
40 Hz
Re
6.6 ohm
Qms
4.4
Qes
0.39
Qts
0.36
Vas
196 l
Cms
181 µm / N
Rms
4.9 kg/s
Efficiency %
3.3
Sd
0.088 m²
Xmax
6 mm
Vd
350 cm³
Le @1 kHz
1 mH
CONSTRUCTION DETAILS
Net weight
7.2 kg 15.9 lb
Total weight
8.10 kg – 17.86 lb
Magnet
Neodymium
