driver Beyma CP800Ti

Acasa/Difuzoare/înalte/driver Beyma CP800Ti

driver Beyma CP800Ti

In Stock

263,95  + TVA





Putere: 100W AES peste 500 Hz, program 200W peste 500 Hz
Sensibilitate: 112 dB/ 1W/1M cuplat la horn
Domeniu de frecvență: 500-20000 Hz
Impedanță: 8 Ohm
Diametru ieșire: 50,8 mm 2 in
Diametru bobină: 100 mm 4 in
Preț kit reparații: 124,95 EURO+TVA





TECHNICAL SPECIFICATIONS



Throat diameter 50.8 mm 2 in
Nominal impedance 8 Ohm
Minimum impedance 7 ohm @ 0.8 kHz
Re 5.6 ohm
Power capacity 100 W AES above 500 Hz
Program power 200 W above 500 Hz
Sensitivity 112 dB 1 W @ 1 m coupled to horn
Frequency range 500-20000 Hz
Recom. crossover frequency 500 Hz or higher (12 dB/oct. min slope)
Voice coil diameter 101.6 mm 4 in
Flux density 1.75 T
BL factor 15 N/A
Diaphragm material Titanium

CONSTRUCTIVE DETAILS



External diameter 228 mm 9 in
Depth 117 mm 4.6 in
Mounting Four M6 threaded holes. 90º apart on
101.6 mm (4 in) diameter circle.
Mounting hardware is supplied
Net weight 10.3 kg 20.6 lb
Total weight 11 kg 22 lb
Magnet Ferrite
