driver Beyma SMC8060/N

driver Beyma SMC8060/N

In Stock

77,95  + TVA





Putere: 50W AES peste 1,5 KHz, program 100W peste 1,5 KHz
Sensibilitate: 107 dB/ 1W/ 1M
 Domeniu de frecvență: 800-18000 Hz
Impedanță: 8 Ohm
Diametru ieșire: 25,4 mm 1 in
Diametru bobină: 44,4 mm 1,75 in
Preț kit reparații: 32,95 EURO+TVA





TECHNICAL SPECIFICATIONS



Throat diameter 25 mm 1 in
Nominal impedance 8 Ohm
Minimum impedance 5 ohm @ 4kHz
Re 4.4 ohm
Power capacity 50 W AES above 1.5 kHz
Program power 100 W above 1.5 kHz
Sensitivity 107 dB 1 W @ 1 m
Frequency range 800-18000 Hz
Recom. crossover frequency 1.5 kHz or higher (12dB/oct min slope)
Voice coil diameter 44.3 mm 1.75 in
Flux density 1.65 T
BL factor 8.5 N / A
Diaphragm material Polyester

CONSTRUCTIVE DETAILS



External diameter 140×140 mm 5.51×5.51 in
Depth 121 mm 4.76 in
Cutout diameter 130×115 mm 5.12 x 4.53 in
Net weight 1.5 kg 3.3 lb
Total weight 1.7 kg 3.74 lb
Magnet Ferrite
