driver Beyma WL-3Fe

In Stock

70,95  + TVA

Putere: 70W AES peste 1,8 kHz, program 140W peste 1,8 kHz
Sensibilitate: 102 dB/ 1W/1M
Domeniu de frecvență: 1000-18000 Hz
Impedanță: 8 Ohm
Diametru ieșire: 20.5 mm 0.8 in
Diametru bobină: 44.4 mm 1.75 in
Dispersie: 90° x 5°

Descărcări: beyma-speakers-data-sheet-compression-driver-wave-guide-WL3F

Preț kit reparații: 28,95 EURO+TVA

TECHNICAL SPECIFICATIONS



Throat diameter
20.5 mm 0.8 in
Flange height
76.2 mm 3 in
Nominal impedance
8 Ohm
Minimum impedance
5.1 ohm @ 3.5 kHz
Re
4.3 ohm
Power capacity
70 W AES above 1.8 kHz
Program power
140 W above 1.8 kHz
Sensitivity
102 dB 1W / 1m @ ZN coupled to a 90º x 5º horn
Frequency range
1000-18000 Hz
Recom. crossover frequency
1.8 kHz or higher (12dB/oct pend. min.)
Voice coil diameter
44.3 mm 1.75 in
Flux density
1.6 T
BL factor
4.8 N/A
Diaphragm material
PM4

CONSTRUCTION DETAILS

Total weight
1.8 kg 3.96 lb
External diameter
115 mm 4.5 in
Depth
150 mm 5.91 in
Mounting
Four 6 mm diameter holes
Net weight
1.7 kg 3.75 lb
Total weight (2 units)
3.6 kg 7.94 lb.
Magnet
Ferrite

TECHNOLOGIES

PM4
