tweeter TPL75

tweeter TPL75

In Stock

283,95  + TVA

Putere: 40W AES peste 1 kHz, program 80W peste 1 kHz
Sensibilitate: 92 dB/ 1W/1M
Domeniu de frecvență: 1000-23000 Hz
Impedanță: 8 Ohm
Frecvență crossover recomandată: 1 kHz or higher (12 dB/oct. min slope)
Magnet: Neodymium
Preț kit reparații: 64,95 EURO+TVA

Descărcări: beyma-speakers-data-sheet-amt-TPL75

TECHNICAL SPECIFICATIONS



Nominal impedance
8 Ohm
Electrical resistance
4.9 ohm
Power capacity
40 W AES above 1.2 kHz
Program power
80 W above 1.2 kHz
Sensitivity
92 dB 1 W/1 m @ ZN
Frequency range
1000-23000 Hz
Recom. crossover frequency
1.2 kHz or higher (12dB/oct min slope)

CONSTRUCTION DETAILS



Overall dimensions
123 x 112 x 38 mm // 4.8 x 4.4 x 1.5 in
Net weight
0.7 kg 1.54 lb
Total weight
0.8 kg 1.76 lb
Magnet
Neodymium
Baffle cutout dimensions
100×86 mm 3.9×3.4 in
