difuzor Beyma 10MC700Nd

Acasa/Difuzoare/10 inch/difuzor Beyma 10MC700Nd
Nou

difuzor Beyma 10MC700Nd

In Stock

175,00  + TVA

putere  700 W AES
sensibilitate  97 dB @ 2.83V @ 1m
domeniu de frecvenţă  60 – 4000 HZ
impedanţă  8 ohm
frecvenţă rezonanţă  56 Hz

10MC700Nd

TECHNICAL SPECIFICATIONS



Nominal diameter

250 mm 10 in

Nominal impedance

8 Ohm

Minimum impedance

7.3 ohm

Power capacity

700 W AES

Program power

1400 W

Sensitivity

97 dB 1 W @ 1 m @ ZN

Frequency range

60-4000 Hz

Recommended enclosure volume

14 l

Voice coil diameter

76.2 mm 3 in

BL factor

21.5 N/A

Moving mass

0.055 kg

Winding length

18 mm

Air gap height

10 mm

Xdamage pp

48 mm

THIELE SMALL PARAMETERS



Fs

56 Hz

Re

5.2 ohm

Qms

3.9

Qes

0.22

Qts

0.21

Vas

25.5 l

Cms

148 µm / N

Rms

4.9 kg/s

Efficiency %

2

Sd

0.035 m²

Xmax

7 mm

Vd

245 cm³

Le @1 kHz

1mH

CONSTRUCTIVE DETAILS



Depth

126 mm 5 in

Net weight

3.6 kg 7.92 lb

Total weight

4.1 kg 9.04 lb

Magnet

Neodymium

TECHNOLOGIES

MALT CROSS
