difuzor Beyma 12P1000Nd

Acasa/Difuzoare/12 inch/difuzor Beyma 12P1000Nd
beyma-speakers-product-picture-low-mid-frequency-12P1000Nd

difuzor Beyma 12P1000Nd

In Stock

345,95  + TVA

putere:
900 W AES
sensibilitate:
96 dB/1W/1M
domeniu de frecvenţă:
30-2500 Hz
impedanţă:
8 Ohm
frecvenţă rezonanţă:
47 Hz
preţ kit reparaţii:
117,95 Euro+TVA
Descărcări:12P1000Nd



TECHNICAL SPECIFICATIONS



Nominal diameter 300 mm 12 in
Nominal impedance 8 Ohm
Minimum impedance 6.5 ohm
Power capacity 900 W AES
Program power 1800 W
Sensitivity 96 dB 1 W @ 1 m @ 2Π
Frequency range 30-2500 Hz
Recommended enclosure volume 20 / 60 l 0.7 / 2.24 ft³
Voice coil diameter 100 mm 4 in
BL factor 25.3 N / A
Moving mass 0.100 kg
Winding length 21 mm
Air gap height 12 mm
Xdamage pp 52 mm

THIELE SMALL PARAMETERS



Fs 47 Hz
Re 5.1 ohm
Qms 7.89
Qes 0.27
Qts 0.26
Vas 49 l
Cms 115 µm / N
Rms 3.7 kg / s
Efficiency % 1.8
Sd 0.055 m²
Xmax 8 mm
Vd 440 cm³
Le @1 kHz 2 mH

CONSTRUCTIVE DETAILS



Net weight 5.4 kg 11.88 lb
Total weight 6.1 kg 13.42 lb
Magnet Neodymium
