difuzor Beyma 15LEX1000Nd

Acasa/Difuzoare/15 inch/difuzor Beyma 15LEX1000Nd
Nou

difuzor Beyma 15LEX1000Nd

In Stock

284,95  + TVA

putere:
1000 W AES
sensibilitate:
97 dB/1W/1M
domeniu de frecvenţă:
40-1500 Hz
impedanţă:
8 Ohm
frecvenţă rezonanţă:
41 Hz
preţ kit reparaţii:
————
Descărcări: 15LEX1000Nd

15LEX1000Nd

TECHNICAL SPECIFICATIONS



Nominal diameter

380 mm 15 in

Nominal impedance

8 Ohm

Minimum impedance

6.8 ohm

Power capacity

1000 W AES

Program power

2000 W

Sensitivity

97 dB 1 W/1 m @ ZN

Frequency range

40-1500 Hz

Recommended enclosure volume

115 l

Voice coil diameter

88.9 mm 3.5 in

BL factor

21.9 N/A

Moving mass

0.147 kg

Winding length

25 mm

Air gap height

12 mm

Xdamage pp

65 mm

THIELE SMALL PARAMETERS



Fs

41 Hz

Re

5.2 ohm

Qms

3.9

Qes

0.41

Qts

0.37

Vas

113 l

Cms

103 µm / N

Rms

9.7 kg/s

Efficiency %

1.8

Sd

0.088 m²

Xmax

10 mm

Vd

880 cm³

Le @1 kHz

1.1 mH

CONSTRUCTIVE DETAILS



Depth

189 mm 7.4 in

Net weight

6.7 kg 14.8 lb

Total weight

7.7 kg 17 lb

Magnet

Neodymium
