difuzor Beyma 18LEX1000Nd

Acasa/Difuzoare/18 inch/difuzor Beyma 18LEX1000Nd
Nou

difuzor Beyma 18LEX1000Nd

In Stock

282,95  + TVA

putere:
1000 W AES
sensibilitate:
98 dB/1W/1M
domeniu de frecvenţă:
35-1000 Hz
impedanţă:
8 Ohm
frecvenţă rezonanţă:
34 Hz
preţ kit reparaţii:
———-
Descărcări: 18LEX1000Nd

TECHNICAL SPECIFICATIONS



Nominal diameter

460 mm 18 in

Nominal impedance

8 Ohm

Minimum impedance

6.5 ohm

Power capacity

1000 W AES

Program power

2000 W

Sensitivity

98 dB 1 W/1 m @ ZN

Frequency range

35-1000 Hz

Voice coil diameter

88.9 mm 3.5 in

BL factor

22 N/A

Moving mass

0.185 kg

Winding length

25 mm

Air gap height

12 mm

Xdamage pp

65 mm





THIELE SMALL PARAMETERS



Fs

34 Hz

Re

5.1 ohm

Qms

5.6

Qes

0.42

Qts

0.39

Vas

260 l

Cms

117 µm / N

Rms

7.1 kg / s

Efficiency %

2.4

Sd

0.1255 m²

Xmax

10 mm

Vd

1255 cm³

Le @1 kHz

1.6 mH

CONSTRUCTIVE DETAILS



Depth

233 mm 9.2 in

Net weight

7.3 kg 16.1 lb

Total weight

8.6 kg 18.9 lb

Magnet

Neodymium



TECHNOLOGIES

MALT CROSS
