difuzor Beyma 15P1000Fe V2

Acasa/Difuzoare/15 inch/difuzor Beyma 15P1000Fe V2

difuzor Beyma 15P1000Fe V2

In Stock

201,90  + TVA

putere : 1000W AES
sensibilitate : 98 dB @ 2.83V @ 1m
domeniu de frecvenţă : 45 – 2000Hz
impedanţă : 8 ohm
frecvenţă rezonanţă : 45Hz
preţ kit reparaţii : 86,90 Euro + TVA



TECHNICAL SPECIFICATIONS



Nominal diameter 380 mm 15 in
Nominal impedance 8 Ohm
Minimum impedance 6.8 ohm
Power capacity 1000 W AES
Program power 2000 W
Sensitivity 98 dB 1 W @ 1 m @ ZN
Frequency range 45-2000 Hz
Recommended enclosure volume 30 / 120 l 1.06 / 4.24 ft.³
Voice coil diameter 101.6 mm 4 in
BL factor 27.4 N/A
Moving mass 0.157 kg
Winding length 20 mm
Air gap height 12 mm
Xdamage pp 52 mm

THIELE SMALL PARAMETERS



Fs 45 Hz
Re 5.2 ohm
Qms 5.86
Qes 0.31
Qts 0.3
Vas 80.7 l
Cms 78 µm / N
Rms 7.6 kg/s
Efficiency % 2.4
Sd 0.0855 m²
Xmax 8 mm
Vd 684 cm³
Le @1 kHz 1.5 mH

CONSTRUCTIVE DETAILS



Depth 170 mm 6.70 in
Net weight 13.1 kg 28.9 lb
Total weight 14.1 kg 15.6 lb
Magnet Ferrite
