difuzor Beyma 18G550

Acasa/Difuzoare/18 inch/difuzor Beyma 18G550

difuzor Beyma 18G550

In Stock

323,95  + TVA



putere:
900 W AES
sensibilitate:
98 dB/1W/1M
domeniu de frecvenţă:
25–1500 Hz
impedanţă:
8 Ohm
frecvenţă rezonanţă:
33 Hz
preţ kit reparaţii:
151.95 Euro+TVA
Descărcări: 18G550

TECHNICAL SPECIFICATIONS



Nominal diameter

460 mm 18 in

Nominal impedance

8 Ohm

Minimum impedance

6.8 ohm

Power capacity

900 W AES

Program power

1800 W

Sensitivity

97 dB 1 W @ 1 m @ ZN

Frequency range

35-1500 Hz

Recommended enclosure volume

80 / 200 l 2.8 / 7 ft³

Voice coil diameter

114 mm 4.5 in

BL factor

23.4 N/A

Moving mass

0.204 kg

Winding length

25 mm

Air gap height

12 mm

Xdamage pp

40 mm

THIELE SMALL PARAMETERS



Fs

33 Hz

Re

5.6 ohm

Qms

7

Qes

0.42

Qts

0.4

Vas

290 l

Cms

117 µm / N

Rms

6 kg / s

Efficiency %

2.25

Sd

0.1320 m²

Xmax

10 mm

Vd

1320 cm³

Le @1 kHz

1.8 mH

CONSTRUCTIVE DETAILS

Net weight

12.60 kg 27.78 lb

Total weight

14.50 kg 31.97 lb

Magnet

Ferrite
