difuzor Beyma 6G40Nd

Acasa/Difuzoare/6 inch/difuzor Beyma 6G40Nd

difuzor Beyma 6G40Nd

In Stock

86,95  + TVA



putere: 170W AES,
sensibilitate: 95dB/1W/1M,
domeniu de frecvenţă: 70-9000Hz,
impedanţă: 8 ohm,
frecvenţă rezonanţă: 88Hz,
preţ kit reparaţii: 35,95 Euro+TVA





TECHNICAL SPECIFICATIONS



Nominal diameter 165 mm 6.5 in
Nominal impedance 8 Ohm
Minimum impedance 7 ohm
Power capacity 170 W AES
Program power 340 W
Sensitivity 95 dB 1 W @ 1m @ 2Π
Frequency range 70-9000 Hz
Recommended enclosure volume 10 / 30 l 0.35 / 1.06 ft.³
Voice coil diameter 51.7 mm 2 in
BL factor 11 N /A
Moving mass 0.012 kg
Winding length 9 mm
Air gap height 7 mm
Xdamage pp 20 mm

THIELE SMALL PARAMETERS



Fs 88 Hz
Re 6.2 ohm
Qms 9.1
Qes 0.34
Qts 0.33
Vas 7.2 l
Cms 260 µm / N
Rms 0.76 kg / s
Efficiency % 1.4
Sd 0.014 m²
Xmax 1 mm
Vd 14 cm³
Le @1 kHz 0.6 mH

CONSTRUCTIVE DETAILS



Net weight 1.7 kg 3.74 lb
Total weight 2.3 kg 5.06 lb
Magnet Neodymium
