difuzor Beyma 6MCF200Nd

Acasa/Difuzoare/6 inch/difuzor Beyma 6MCF200Nd

difuzor Beyma 6MCF200Nd

In Stock

210,95  + TVA

putere: 200W AES,
sensibilitate: 97dB/1W/1M,
domeniu de frecvenţă: 400-12000Hz,
impedanţă: 8 ohm,
frecvenţă rezonanţă: 410Hz,
preţ kit reparaţii:  50,95 Euro + TVA



TECHNICAL SPECIFICATIONS



Nominal diameter 165 mm 6.5 in
Nominal impedance 8 Ohm
Minimum impedance 8 ohm
Power capacity 200 W AES
Program power 400 W
Sensitivity 97 dB 1 W @ 1 m @ ZN
Frequency range 400-12000 Hz
Voice coil diameter 51.7 mm 2 in
BL factor 19.2 N/A
Moving mass 0.016 kg
Winding length 9.2 mm
Air gap height 9 mm
Xdamage pp

THIELE SMALL PARAMETERS



Fs 410 Hz
Re 6.3 ohm
Qms 5.9
Qes 0.72
Qts 0.64
Vas 0.25 l
Cms 9 µm / N
Rms 7.1 kg/s
Efficiency % 2.4
Sd 0.014 m²
Xmax 2.5 mm
Vd 35 cm³
Le @1 kHz 0.25 mH

CONSTRUCTIVE DETAILS



Depth 75 mm 2.95 in
Net weight 2.3 kg 5.07 lb
Total weight 2.7 kg 5.94 lb
Magnet Neodymium
