difuzor Beyma 6G40Fe

Acasa/Difuzoare/6 inch/difuzor Beyma 6G40Fe

difuzor Beyma 6G40Fe

In Stock

58,95  + TVA



putere: 170W AES,
sensibilitate: 94dB/1W/1M,
domeniu de frecvenţă: 70-5000Hz,
impedanţă: 8 ohm,
frecvenţă rezonanţă: 100Hz,
preţ kit reparaţii: 36,95 Euro+TVA





TECHNICAL SPECIFICATIONS



Nominal diameter 165 mm 6.5 in
Nominal impedance 8 Ohm
Minimum impedance 7.9 ohm
Power capacity 170 W AES
Program power 340 W
Sensitivity 94.3 dB 1 W @ 1m @ 2Π
Frequency range 70-9000 Hz
Recommended enclosure volume 10 / 30 l 0.35 / 1.06 ft.³
Voice coil diameter 51.7 mm 2 in
BL factor 11 N /A
Moving mass 0.013 kg
Winding length 9.2 mm
Air gap height 7 mm
Xdamage pp 37.8 mm

THIELE SMALL PARAMETERS



Fs 102 Hz
Re 6 ohm
Qms 9.25
Qes 0.42
Qts 0.4
Vas 5.04 l
Cms 184 µm / N
Rms 0.91 kg / s
Efficiency % 1.24
Sd 0.014 m²
Xmax 3.1 mm
Vd 14 cm³
Le @1 kHz 0.5 mH

CONSTRUCTIVE DETAILS



Net weight 3.02 kg 6.66 lb
Total weight 3.12 kg 6.88 lb
Magnet Ferrite
