difuzor Beyma 6P200Nd

Acasa/Difuzoare/6 inch/difuzor Beyma 6P200Nd

difuzor Beyma 6P200Nd

In Stock

94,95  + TVA

putere: 200W AES,
sensibilitate: 92dB/1W/1M,
domeniu de frecvenţă: 60-9000Hz,
impedanţă: 8 ohm,
frecvenţă rezonanţă: 56Hz,
preţ kit reparaţii: 50,95 Euro + TVA





TECHNICAL SPECIFICATIONS



Nominal diameter 165 mm 6.5 in
Nominal impedance 8 Ohm
Minimum impedance 5.8 ohm
Power capacity 200 W AES
Program power 400 W
Sensitivity 92 dB 1 W @ 1m @ 2Π
Frequency range 60-9000 Hz
Recommended enclosure volume 6 / 20 l 0.21 / 0.71 ft.³
Voice coil diameter 51.7 mm 2 in
BL factor 10.5 N /A
Moving mass 0.017 kg
Winding length 14 mm
Air gap height 7 mm
Xdamage pp 20 mm

THIELE SMALL PARAMETERS



Fs 56 Hz
Re 5.3 ohm
Qms 3.69
Qes 0.32
Qts 0.29
Vas 11.9 l
Cms 468 µm / N
Rms 1.6 kg / s
Efficiency % 0.65
Sd 0.0135 m²
Xmax 5.5 mm
Vd 74.25 cm³
Le @1 kHz 0.6 mH

CONSTRUCTIVE DETAILS



Net weight 1.9 kg 4.18 lb
Total weight 2.4 kg 5.29 lb
Magnet Neodymium
