difuzor Beyma 8MI100

difuzor Beyma 8MI100

In Stock

62,90  + TVA

putere : 250W AES
sensibilitate : 98dB @ 2.83V @ 1m
domeniu de frecvenţă : 150 – 7000Hz
impedanţă : 8 ohm
frecvenţă rezonanţă : 90Hz
preţ kit reparaţii : 40,90 Euro + TVA

Difuzor beyma 8mi100 – un difuzor midbass cu o putere de 250W AES folosit in sisteme audio profesionale.

TECHNICAL SPECIFICATIONS



Nominal diameter 200 mm 8 in
Nominal impedance 8 Ohm
Minimum impedance 6.9 ohm
Power capacity 250 W AES
Program power 500 W
Sensitivity 98 dB 1 W @ 1 m @ 2Π
Frequency range 150-7000 Hz
Voice coil diameter 51.7 mm 2 in
BL factor 9.8 N /A
Moving mass 0.017 kg
Winding length 9 mm
Air gap height 7 mm

THIELE SMALL PARAMETERS



Fs 90 Hz
Re 6 ohm
Qms 8.5
Qes 0.6
Qts 0.56
Vas 13 l
Cms 186 µm / N
Rms 1.2 kg / s
Efficiency % 1.5
Sd 0.022 m²
Xmax 1 mm
Vd 22 cm³
Le @1 kHz 0.2 mH

CONSTRUCTIVE DETAILS



Net weight 3.1 kg 6.83 lb
Total weight 3.25 kg 7.15 lb
Magnet Ferrite
