driver Beyma CP755Ti

beyma-speakers-product-picture-compression-drivers-CP755Ti

driver Beyma CP755Ti

In Stock

201,95  + TVA





Putere: 70W AES peste 800 Hz, program 140W peste 800 Hz
Sensibilitate: 110 dB/ 1W/1M cuplat la horn
Domeniu de frecvență: 600-20000 Hz
Impedanță: 8 Ohm
Diametru ieșire: 36 mm 1,4 in
Diametru bobină: 72,2 mm 2,9 in
Preț kit reparații: 62,95 EURO+TVA





TECHNICAL SPECIFICATIONS



Throat diameter 36 mm 1.4 in
Nominal impedance 8 Ohm
Minimum impedance 7.3 ohm @ 3.5 kHz
Re 5.5 ohm
Power capacity 70 W AES above 800 Hz
Program power 140 W above 800 Hz
Sensitivity 110 dB 1 W @ 1 m coupled to horn
Frequency range 600-20000 Hz
Recom. crossover frequency 800 Hz or higher (12 dB/oct. min slope)
Voice coil diameter 72.2 mm 2.9 in
Flux density 1.875 T
BL factor 10 N / A
Diaphragm material Titanium dome with polyester surround

CONSTRUCTIVE DETAILS



External diameter 192 mm 7.56 in
Depth 78 mm 3.07 in
Mounting Four M6 threaded holes. 90º apart on
101.6 mm (4 in) diameter circle.
Mounting hardware is supplied
Net weight 6.75 kg 14.85 lb
Total weight 7 kg 15.4 lb
Magnet Ferrite
