tweeter Beyma CP/09

tweeter Beyma CP/09

In Stock

41,95  + TVA

Putere: 15 W AES , program 30 W
Sensibilitate: 104 dB /1W /1M
Domeniu de frecvență: 2000-20000 Hz
Impedanță: 8 Ohm
Frecvență crossover recomandată: 6 kHz or higher (12 dB/oct. min slope)
Dispersie: 90ºx60º
Preț kit reparații: 19,95 EURO+TVA

Descărcări: beyma-speakers-data-sheet-compression-tweeter-CP09

TECHNICAL SPECIFICATIONS



Nominal impedance
8 Ohm
Minimum impedance
7.5 ohm @ 8 kHz
Sensitivity
104 dB 1 W @ 1 m coupled to horn
Re
5 ohm
Frequency range
2000-20000 Hz
Power capacity
15 W AES
Program power
30 W
Recom. crossover frequency
6 kHz or higher (12 dB/oct. min slope)
Dispersion HxV
90º x 60º
Voice coil diameter
25.8 mm 1 in
Flux density
1.4 T
BL factor
4 N/A
Diaphragm material
Aluminium

CONSTRUCTION DETAILS



External diameter
98×92 mm 3.85×3.6 in
Depth
96 mm 3.78 in
Cutout diameter
90×70 mm 3.54×2.75 in
Net weight
0.6 kg 1.32 lb
Total weight
0.85 kg 1.87 lb
Magnet
Ferrite
