difuzor Beyma 8BR40/N

Acasa/Difuzoare/8 inch/difuzor Beyma 8BR40/N

difuzor Beyma 8BR40/N

In Stock

48,95  + TVA



putere:
50W AES,
sensibilitate:
91 dB/1W/1M,
domeniu de frecvenţă:
30-6000Hz,
impedanţă:
8 ohm,
frecvenţă rezonanţă:
30 Hz,
preţ kit reparaţii:
—————–



TECHNICAL SPECIFICATIONS



Nominal diameter 200 mm 8 in
Nominal impedance 8 Ohm
Minimum impedance 6.4 ohm
Power capacity 50 W AES
Program power 100 W
Sensitivity 91 dB 1 W @ 1m @ 2Π
Frequency range 30-6000 Hz
Recommended enclosure volume 20 / 60 l 0.7 / 2.12 ft.³
Voice coil diameter 25,4 mm 1 in
BL factor 6.8 N /A
Moving mass 0.021 kg
Winding length 16 mm
Air gap height 6 mm
Xdamage pp 20 mm

THIELE SMALL PARAMETERS



Fs 30 Hz
Re 5.5 ohm
Qms 2.05
Qes 0.48
Qts 0.39
Vas 89.1 l
Cms 1301 µm / N
Rms 1.99 kg / s
Efficiency % 0.5
Sd 0.022 m²
Xmax 6.7 mm
Vd 147 cm³
Le @1 kHz 0.5 mH

CONSTRUCTIVE DETAILS



Net weight 1.35 kg 2.97 lb
Total weight 1.55 kg 3.41 lb
Magnet Ferrite
