driver Beyma CD-11Fe

Acasa/Difuzoare/înalte/driver Beyma CD-11Fe
Nou

driver Beyma CD-11Fe

In Stock

60,00  + TVA

putere : 70W AES peste 1,2 kHz; 140W peste 1,2 kHz
sensibilitate : 109 dB @ 2,83 V @ 1 m
domeniu de frecvenţă : 0,7 – 19 kHz
  • se poate opta și pentru varianta cu filet .

CD-11Fe

TECHNICAL SPECIFICATIONS



Throat diameter

25.4 mm 1 in

Nominal impedance

8 Ohm

Minimum impedance

5.2 ohm

Re

4.4 ohm

Power capacity

70 W AES above 1.2 kHz

Program power

140 W above 1.2 kHz

Sensitivity

109 dB 1W / 1m @ ZN coupled to TD-164

Frequency range

700-19000 Hz

Voice coil diameter

44.4 mm 1.75 in

Flux density

1.5 T

Diaphragm material

PM4

CONSTRUCTIVE DETAILS



External diameter

110 mm 4.3 in

Depth

59 mm 2.3 in

Mounting

Three M5 threaded holes. 120º apart on

57 mm (2.24 in) diameter circle.

Two M5 threaded holes. 180º apart on

76.2 mm (3 in) diameter circle.

Net weight

1.8 kg 4 lb

Total weight

1.9 kg 4.2 lb

Magnet

Ferrite

TECHNOLOGIES

PM4
