driver Beyma CD1014Fe/N

Acasa/Difuzoare/înalte/driver Beyma CD1014Fe/N

driver Beyma CD1014Fe/N

In Stock

68,95  + TVA



Putere: 70W AES peste 1,2 kHz, program 140W peste 1,2 kHz
Sensibilitate: 110 dB/1W/ 1M cuplat la horn
Domeniu de frecvență: 700-19000 Hz
Impedanță: 8 Ohm
Diametru ieșire: 36 mm 1,4 in
Diametru bobină: 44,4 mm 1,75 in
Preț kit reparații: 26,95 EURO+TVA





TECHNICAL SPECIFICATIONS



Throat diameter 36 mm 1.4 in
Nominal impedance 8 Ohm
Minimum impedance 5.2 ohm @ 3.5 kHz
Re 4.3 ohm
Power capacity 70 W AES above 1.2 kHz
Program power 140 W above 1.2 kHz
Sensitivity 110 dB 1 W @ 1 m coupled to horn
Frequency range 700-19000 Hz
Recom. crossover frequency 1.2 kHz or higher (12dB/oct min slope)
Voice coil diameter 44.4 mm 1.75 in
Flux density 1.65 T
BL factor 6.6 N/A
Diaphragm material PM4

CONSTRUCTIVE DETAILS



External diameter 120 mm 4.72 in
Depth 66 mm 2.60 in
Mounting Four M5 threaded holes. 90º apart on
101.6 mm (4 in) diameter circle.
Net weight 2 kg 4.4 lb
Total weight 2.7 kg 5.94 lb
Magnet Ferrite
