driver Beyma WL-4Fe/N

beyma-speakers-product-picture-compression-driver-wave-guide-WL4FeN

driver Beyma WL-4Fe/N

In Stock

93,95  + TVA

Putere: 70W AES peste 1,2 kHz, program 140W peste 1,2 kHz
Sensibilitate: 104 dB/ 1W/1M
Domeniu de frecvență: 700-20000 Hz
Impedanță: 8 Ohm
Diametru ieșire: 20.5 mm 0.8 in
Diametru bobină: 44.4 mm 1.75 in
Dispersie: 90° x 5°

Descărcări: beyma-speakers-data-sheet-compression-driver-wave-guide-WL4FeN

Preț kit reparații: 28,95 EURO+TVA

TECHNICAL SPECIFICATIONS



Throat diameter
20.5 mm 0.8 in
Flange height
101.6 mm 4 in
Nominal impedance
8 Ohm
Minimum impedance
4.71 ohm @ 3.4kHz
Re
4.3 ohm
Power capacity
70 W AES above 1.2 kHz
Program power
140 W above 1.2 kHz
Sensitivity
104 dB 1 W @ 1 m coupled to horn
Frequency range
700-20000 Hz
Recom. crossover frequency
1.2 kHz or higher (12dB/oct min slope)
Voice coil diameter
44.4 mm 1.75 in
BL factor
6.6 N/A
Diaphragm material
PM4

CONSTRUCTION DETAILS

Total weight
External diameter
100 mm 3.9 in
Depth
200 mm 7.87 in
Mounting
Four 6 mm diameter holes
Net weight
1.81 kg 4 lb.
Total weight (2 units)
3.78 kg 8.34 lb.
Magnet
Ferrite

TECHNOLOGIES

PM4
