driver Beyma SMC225Nd

driver Beyma SMC225Nd

In Stock

108,95  + TVA





Putere: 40W AES peste 1,5 KHz, program 80W peste 1,5 KHz
Sensibilitate: 108 dB/ 1W/1M cuplat la TD-164
Domeniu de frecvență: 800-20000 Hz
Impedanță: 8 Ohm
Diametru ieșire: 25,4 mm 1 in
Diametru bobină: 44,4 mm 1,75 in
Preț kit reparații: 41,95 EURO+TVA





TECHNICAL SPECIFICATIONS



Throat diameter 25 mm 1 in
Nominal impedance 8 Ohm
Minimum impedance 5.5 ohm @ 4.5 kHz
Re 5.6 ohm
Power capacity 40 W AES above 1.5 kHz
Program power 80 W above 1.5 kHz
Sensitivity 108 dB 1 W @ 1 m coupled to horn
Frequency range 800-20000 Hz
Recom. crossover frequency 1.5 kHz or higher (12dB/oct min slope)
Voice coil diameter 44.3 mm 1.75 in
Flux density 1.8 T
BL factor 8 N/A
Diaphragm material Polyester

CONSTRUCTIVE DETAILS



External diameter 80 mm 3.15 in
Depth 57 mm 2.24 in
Mounting Three M4 threaded holes. 120º apart on
57 mm (2.24 in) diameter circle.
Mounting hardware is supplied
Net weight 0.7 kg 1.54 lb
Total weight 0.8 kg 1.76 lb
Magnet Neodymium
